Ferry Smart low power microwave radar module Ultra-small 5.8G radar module, a new upstart in the security field
Introduction of the new upstart in the field of Ferry Smart low power microwave radar module security
In recent years, with the constant change of security market demand, the traditional security point-to-point intrusion detection method can not fully meet the needs of users, especially for outdoor security, high-risk places or judicial organs, the detector needs to have a certain detection range.
The launch of feiruai series full digital microwave radio (radar) low power microwave radar module effectively solves the market problem. Microwave radar is composed of microwave transmitter and microwave receiver. It is installed face to face when used, and a three-dimensional protection zone is formed between the transmitter and receiver. The highest height of the reserve is 2.5 meters, the widest width is 3.5 meters, and the distance of protection can reach 50 meters. As long as the intruder can be effectively detected in the whole protection area, immediately upload the alarm information and linkage monitoring video, notify the personnel on duty to deal with the alarm situation. The whole process realizes fast response, accurate positioning and timely processing, forming a perfect alarm system. That is, while the intruder is still moving near the radar, he has been reliably detected, so that it can be detected and dealt with early, and criminals can be deterred in time.
Ferry Smart low power microwave radar module in fast debugging mode microwave counterfire makes up for the defects of the traditional radar detection mode, with good sealing, wide detection range, accurate alarm, mutual interference and other advantages, will be developed into a broader security field in the future!
Advantages of low power microwave radar module:
1. Fast debugging mode design, receiver equipped with OLED screen and function button, real-time display of working parameters, debugging (patented technology) can be completed quickly without external tools.
2, 1~255 precision signal amplification compensation, according to the alarm value set by the user, carefully analyze the signal changes caused by the occlusion of different volume objects, make accurate judgment.
3, adopt precision rake algorithm, effectively filter possible false positives, only alarm real invasion; Intelligent temperature compensation and environment adaptive design, calm to cope with complex environment.
4, patent appearance, shell using imported PC material thickening, anti-aging, anti-violence damage, durable; Sealed waterproof design, protection class up to IP67, suitable for indoor and outdoor environment installation.
5. 130 level alarm trigger voltage can be selected. Users can set trigger conditions arbitrarily according to the site environment and the size of the target object, which has better stability and applicability.
6, can choose four working frequency, can realize 360° cross around the target area without dead Angle prevention, detectors do not interfere with each other; OLED screen automatic sleep design, energy saving and environmental protection. Three-dimensional protection design, invaders can drill, climb, squat,!
Feizhineng has released the industry's ultra-small size low power 5.8G radar module
When it comes to the 5.8G radar module, many people say it is expensive, consumes a lot of power, and has a large size. These problems have plagued the industry for a long time, and the industry has been working on solutions.
The fr58L4LD-1212D microwave radar module is the first of its kind. This module can solve all the above problems at the same time to meet customers' needs of low cost and high performance.
In terms of low power consumption, theoretically, power consumption is proportional to the transmitted power and also proportional to the induction range. Ferry Smart adopts intermittent launch technology to dramatically reduce product power consumption. At the same time, the induction range is not reduced, but the power consumption is only UA level, which can replace PIR products and directly use battery power, subverting the concept that radar modules cannot use battery power.
In terms of volume, due to the use of microstrip line as transceiver antenna, almost no space, the volume is only 12*12mm, the area is close to the fingernail. In the application of client products, especially some products with limited space size will be well applied and upgraded to intelligent products, greatly improving the added value of client products.
Application scenarios of low-power microwave radar module:
1. The intelligent garbage can automatically opens and closes
As long as the object close to the induction area, the barrel cover will automatically open, objects or hands leave the induction area after a few seconds, the barrel cover will automatically close, do not need external power supply, rely on battery power, low power consumption, clean and hygienic.
2, intelligent induction wardrobe lamp
As long as you open the closet door, the lights will automatically turn on and turn off a few seconds after closing. Due to the extremely low power consumption, you can use battery power to avoid the trouble of plugging in.
3, induction night light
Use battery-powered small night light, break through the socket shackle, bid farewell to tedious installation, sweep away the dark corner, illuminate in the dark, while not dazzling.
